Advanced Machine Vision System for High-Precision Industrial Inspection

1 / 5

Advanced Machine Vision System for High-Precision Industrial Inspection

Customization:	Available
After-sales Service:	Life-Long Maintenance Service
Warranty:	1 Year

Send Inquiry

Product Description

Basic Information

Model NO.	JTD-MV1080CNC
Type	2.5D Video Measuring System
Operate Method	CNC
Linear Scale	Gsi High Accuracy Linear Scale, 0.5um
CCD Camera System	High Resolution Color Network Camera
Lighting System	Continuous Adjustable LED Light
Software	Quickmeasuring
Transport Package	Wooden Case
Specification	700x700x200mm
Origin	China
HS Code	9031499090
Production Capacity	5000 pieces/Year

Product Description

Key Features & Technical Details

CCD Optical System:

Featuring an automatic zoom lens that eliminates the need for manual re-calibration after zooming. The integrated image navigation system allows for rapid localization of the measured object.

Advanced Software Suite:

User-friendly Windows-based interface. Supports multi-geometry processing, DXF file imports, and automatic result recording. Measurement data is calculated and recombined seamlessly.

High Precision Engineering:

Equipped with GSI High Accuracy Linear Scales (0.5 micron resolution) and Japanese Panasonic servo motors to achieve superior double closed-loop control.

Specifications

Model	JTD-MV1080CNC
X,Y-axis Travel(mm)	1000 X 800
Z-axis Travel(mm)	200
Dimensions(mm)	2050 x 1610 x 1700
Resolution(mm)	0.0005
X,Y-axis Accuracy(um)	≤3+L/200
Z-axis Accuracy(um)	≤4+L/200
Illumination	Adjustable LED Ring illumination
CCD	High Resolution Color Network Camera
Optical System	Automatic Zoom Lens
Power	220V±10%, 50HZ

Related Products

Manufacturing Excellence

Global Footprint:

Serving 1,000+ global clients across 50+ countries including the U.S., Germany, France, and Japan. Our instruments are trusted by industry leaders in automotive, aerospace, and electronics sectors such as TCL, BYD, Apple, Samsung, and Foxconn.

Packaging & Certificates

Professional packaging ensures perfect delivery to your hands!

Frequently Asked Questions

Are you a manufacturer or a trading company?

We are a direct factory with 20 years of experience. All precision measuring instruments are designed, developed, and produced in-house.

What are your core strengths in the industry?

Our strength lies in robust R&D, holding over 50 patents. All products meet global standards including ISO and CE.

Do you support product customization for specific needs?

Yes, we provide tailored solutions based on unique customer applications to ensure the system fits your requirements perfectly.

What after-sales support do you offer?

We provide detailed manuals, English instructional videos, and have dedicated after-sales support. On-site installation and training are available in specific countries.

What industries use your precision measuring instruments?

Our equipment serves a wide range of sectors including automotive, aerospace, electronics manufacturing, and high-precision quality control.

How do you ensure international quality standards?

All our production processes follow ISO guidelines, and our instruments are verified by international certifications like CE to ensure reliability for global trade.
