Basic Product Specifications
Layers
Multilayer (1-48 Layers)
Base Material
FR-4 (Tg135-Tg250)
Certification
RoHS, CCC, ISO, UL, IATF16949
Board Thickness
0.2-6.0 mm
Copper Thickness
0.5-12 Oz
Surface Finishing
LF HAL, OSP, ENIG, ENEPIG, Immersion Silver
⚙
PCBA Process & Solutions
PCBA (Printed Circuit Board Assembly) is the core process in modern electronics manufacturing, encompassing the entire production chain from circuit design, PCB fabrication, component placement, soldering, testing, to final assembly. High-precision, high-reliability PCBA processing services are provided utilizing advanced surface mount technology and automated equipment.
📋
Technical Specification
| Product Name | PCBA Process |
| Service Range | PCB + PCBA + Components + Reverse Engineering |
| Surface Finishing | LF HAL, OSP, ENIG, ENEPIG, Immersion Silver, Immersion Tin, Selective Hard Gold |
| Application | Communications, Industrial Control, Semiconductors, Medical, Automotive |
| Production Capacity | 50,000 Units Monthly |
🛠
Manufacturing Capabilities
Expertise covers a wide range of hardware solutions, focusing on high-quality, high-mix low-volume production with fast turnaround times.
- Rigid PCB: Up to 40 layers of complex circuitry.
- FPC & Rigid-Flex: Using high-grade Panasonic and DuPont materials.
- HDI PCB: Advanced laser-drilled hole technology.
- High-Frequency Boards: Specialized Rogers and Arlon materials for signal integrity.
- Assembly Services: Full SMT lines, DIP wave soldering, IC programming, and functional testing.
Package Size
16.00cm * 10.00cm * 10.00cm
Transport Packing
Vacuum, Blister, Plastic, Cartoon
Delivery Time
Within 3 Days for Samples
❓
Frequently Asked Questions
What specific services are provided?
We provide comprehensive solutions including Reverse Engineering, PCB fabrication, PCBA assembly, Stencil fabrication, Components Sourcing, and Functional Testing.
What files are needed for a PCB and PCBA quotation?
For PCB, we need the Quantity, Gerber file, and technical specifications. For PCBA, we require the PCB working file, BOM (Bill of Materials), and any testing documents for functional assessment.
How is product quality guaranteed?
All PCBs undergo AOI and electronic testing. For PCBA, we utilize AOI and X-Ray inspections to ensure quality control, meeting IPC-II standards.
Is there a Minimum Order Quantity (MOQ)?
The MOQ is just 1 piece. We support everything from initial prototypes/samples to full-scale mass production.
What file formats are accepted for production?
We accept common industrial formats such as Gerber files, CAM350, Protel, and ODB+ (.TGZ).
Are files kept confidential?
Yes, we prioritize security and can sign an NDA to ensure all technical files are used strictly for your fabrication requirements.
