High-Precision Automated Glue Dispensing System with CCD Vision

Customization:	Available
After-sales Service:	Provided
Precision:	High Precision

i

Basic Information

Condition:New

Certification:ISO

Warranty:12 Months

Automatic Grade:Automatic

Installation:Vertical

Driven Type:Electric

Product Name:Dispensing Machine

Feature 1:Guaranteed Quality

Feature 2:Customized According to Needs

After-Sale Service:Provided

Origin:China

P

Product Description

High-Precision Automated Glue Dispensing System

Standard Features

Computer control with Windows OS
CCD visual positioning system
Servo motor with ball screw
Inline CCD visual programming or gerber upload
UPS and voltage stabilizer
ESD grounding point
CE certified

Optional Features

Heated valves for viscosity control
35 degree tilt and 360 degree rotation
PCB heater enhances material flow for underfill applications
Precision weight measurement ensures accurate volumetric dispensing
Multiple valves available: Pneumatic jet valve, Slide valve and Screw valve
Laser height detection to calibrate Z axis automatically

Product Advantages

Cost-effective with high-performance.
Non-contact injection valve for smaller dispensing diameter.
Improves reliability and consistency, increasing productivity.
Minimum overflow width of Underfill is only 0.2mm.
Recognize the chip body for higher accuracy than Mark point recognition.
Identity recognition and automatic program call for intelligent manufacturing.

Specifications	iJet-7H Dispensing Machine
Dimension (mm)	L790×W1600×H1600
Dispensing Area (mm)	Dual conveyors/Dual-valve: X:300 Y:200 Z:30 Single conveyor/Single-valve: X:380 Y:480 Z:30
Repeatability (mm)	±0.01
Maximum moving speed (mm/s)	1000
Maximum acceleration (g)	1.5
Standard configuration	Electrostatic interface; LED lighting; CCD visual positioning; 232 scanner socket; Lifting device
Optional configuration	Booster pump; UPS; Barcode scanner; Micro-balance (0.1mg); Laser altimetry (SICK); Dual valve; Dual conveyors; Four-direction tilt
