📊 Basic Specifications
Applicable Material
Metal, PVC, HDPE, PO, PP, PCB
Cooling System
Air / Water Cooling
Technical Class
Continuous Wave Laser
Laser Type
UV / Fiber Laser
Marking Method
Scanning Marking
Production Capacity
100 Units
💡 Product Description
🎯
Application: Marking of electronic products' LOGO, model, and origin identification.
🛠️
Precision: Ideal for food packaging, PVC pipes, and medicine materials (HDPE, PO, PP).
⚡
Versatility: Advanced PCB marking, cutting, and micro-hole drilling (diameter ≤10μm).
⭐ Key Features
❄️
Cold Laser Processing: Small heat-affected zone ensuring high-quality processing without thermal deformation.
🔍
Superfine Marking: Excellent beam quality and small focusing spot for high-precision intricate designs.
🚀
High Efficiency: Rapid marking speed and high precision to boost production throughput.
📉
Low Maintenance: No consumables required, leading to low cost of ownership and long-term stability.
📋 Technical Specifications
| Machine Model | EP-15/25/30-THG-S |
| Laser Wavelength | 355nm |
| Laser Power | 4W / 7W / 10W / 15W / 25W |
| Min. Marking Line Width | 10µm - 15µm |
| Marking Speed | 250 characters/sec |
| Marking Scope | 100*100mm |
| Standard Lens | F160 |
| Pulse Frequency | 10-200kHz |
| Power Supply | AC 220V, 50Hz, 16A |
| Dimensions | 800mm * 950mm * 1630mm |
🤝 Main Product Range
Our core equipment offerings include: Die Bonder, Wire Bonding, Laser Marking (ID IC Wafer), Laser Grooving, Laser Cutting (Glass Ceramics Wafers), Laser Annealing for Si/Sic, and Automatic Dicing Saw Machines.
📦 Packaging & Shipping
❓ Frequently Asked Questions
How do I choose the most suitable machine?
Please provide details regarding your material type, size, and specific functional requirements. Our team will recommend the optimal configuration based on extensive industry experience.
What is the warranty period for the equipment?
We offer a one-year comprehensive warranty along with 24-hour online professional technical support to ensure your operations run smoothly.
What materials can the UV laser mark?
The UV laser is highly versatile and can process metals, plastics (PVC, HDPE, PP), PCB boards, glass, and ceramic materials with minimal heat impact.
Does the machine require consumables?
No, our laser marking systems are designed to operate without consumables, significantly reducing long-term operational costs and maintenance efforts.
What is the cooling method for these machines?
Depending on the specific power model and requirements, the system utilizes either high-efficiency air cooling or water cooling for stable long-term operation.
Can this machine perform micro-hole drilling?
Yes, the system is capable of high-precision micro-hole drilling with diameters as small as d≤10μm, suitable for advanced electronic packaging.
